5 Top Choices for AG10 Battery Substitutes and Their LR44 Differences

When you need an AG10 Battery substitute, consider these 5 options: LR1130, LR54, 389/390, G10A, and the LR44 battery equivalent. Many small gadgets use batteries like these, but size, voltage, and power are crucial for a proper fit.

The LR44 battery equivalent can sometimes work as a replacement, but it might not be compatible with every device. Always verify your device’s requirements before selecting a battery.

Tip: Always check the battery size and voltage before purchasing a new AG10 Battery or its LR44 battery equivalent.

Key Takeaways

• AG10 batteries are used in small things like watches, toys, and key fobs. They are 11.6 mm wide and 3.1 mm thick. They give 1.5 volts of power.

• Some good AG10 substitutes are LR1130, LR54, 389/390, and G10A batteries. These have the same size and voltage. They might have a little different power or chemicals.

• LR44 batteries are just as wide but are thicker at 5.4 mm. They only fit if your device has enough space. They do not always work as a direct swap for AG10.

• Always look at your device manual or old battery code to pick the right one. Buy batteries from trusted brands for good quality and safety.

• Be careful with button cell batteries. Keep them away from kids. Do not throw them in the trash. Recycle them the right way to keep people and nature safe.

AG10 Battery Overview

Uses

The AG10 Battery is found in many small devices. It is small and gives steady power. This makes it a good choice for gadgets that need reliable energy. Some common uses are:

• Calculators

• Watches, both digital and analog

• Toys and light-up gadgets

• Hearing aids for some models

• Laser pointers

• Key fobs and keyless entry devices

• Digital clocks and small desk or wall clocks

• Remote controls for car keys and cameras

• Small flashlights and mini LED lights

• Medical devices like digital thermometers

• Electronic instruments

• Greeting cards and sound modules

Many medical devices use this battery for clear sound and correct readings. You also find it in smart keys, RFID tags, and sensors. For example, a Tesla Model 3 key fob can last over a year with one AG10 Battery. In toys, it powers mini remote control cars and other fun gadgets.

Note: The AG10 Battery works in both low-power and higher-drain devices. This makes it a flexible choice for many things.

Specs

You should know the main details before picking an AG10 Battery. The table below shows the usual values:

This battery gives a steady 1.5 volts. That fits most small electronics. Its capacity is about 50 mAh, so it lasts long in devices that do not use much power. The AG10 Battery uses alkaline chemistry, so you cannot recharge it. Always check these details to make sure the battery fits your device.

AG10 Battery Equivalents

Equivalent Types

When you look for a replacement for your AG10 Battery, you will find many options. Battery makers use different names for the same size and type. You can use these common equivalents in most devices that need an AG10 Battery:

• LR1130

• LR54

• 189

• G10A

You might also see other codes like D189, 389, 390, GP189, L1131, SR1130, SR54, V389, and WL10. These codes all point to batteries with the same size and voltage. Most of these batteries give you 1.5 volts and have a similar capacity. This means you can use them in watches, calculators, toys, and other small electronics.

Note: Always check the battery code on your old battery or in your device’s manual. Some brands use their own codes, but the batteries work the same way.

Compatibility

You want to make sure your new battery fits and works well. Follow these steps to find a compatible substitute:

1. Check your device’s manual or label for the battery type.

2. Take out the old battery and look for model numbers like LR1130, LR54, 189, or G10A.

3. Use an online battery cross-reference chart to match the size, voltage, and capacity.

4. Buy the replacement from a trusted store. Make sure it fits and meets your device’s needs.

If you follow these steps, you will find the right battery every time. You will avoid problems like poor fit or short battery life. Using the correct equivalent keeps your device running smoothly.

1. LR1130

Specs

LR1130 batteries are the same size as many button cells. This helps them fit in lots of small gadgets. The table below shows how LR1130 and AG10 compare:

This battery works well in many small electronics. The voltage and size fit most button cell devices. LR1130 batteries can last up to three years if not used. Their power is between 50 and 80 mAh, depending on the brand.

Fit

You can use LR1130 batteries in devices that need this size. Putting them in is easy if you follow these steps:

1. Find the flat side and the bumpy side of the battery.

2. Turn off your device and open the battery cover.

3. Put the battery in, matching the sides to the contacts.

4. Make sure the battery fits tight and does not wiggle.

5. Close the cover and turn on your device.

Most devices that use AG10 batteries will also work with LR1130. The size and voltage are the same, so you get a good fit and steady power.

Pros & Cons

It is good to know the main upsides and downsides before picking LR1130.

Tip: LR1130 is a good pick for things like watches, calculators, and toys. If you want longer battery life or steadier power, try a silver-oxide battery.

2. LR54

Specs

LR54 batteries are used in many small gadgets. They use alkaline chemistry and give 1.5 volts. The size is like other button cell batteries. The diameter is 11.6 mm. The height is 3.1 mm. This size makes it easy to swap batteries in watches, calculators, and toys. LR54 batteries usually have a higher capacity. They hold between 85 and 90 mAh. This lets your device work longer before you need a new battery.

Tip: Look at the battery compartment for size and voltage before you buy a new battery.

Fit

LR54 batteries work in devices that need this size. Makers design LR54 to fit snug in the right slots. Here are some things to remember when using LR54 batteries:

• LR54 and AG10 have the same diameter and height, so LR54 fits most devices that use this size.

• Always check your device’s manual or battery area for the right code and polarity.

• LR54 fits tight, so it does not move or lose connection inside your device.

• Line up the battery right and put it in gently so you do not break the contacts.

• The battery should sit flat and not wiggle, so your device works well.

If you do these steps, your battery will fit well and give steady power.

Pros & Cons

It is smart to know the good and bad sides before picking LR54 as a substitute.

• Pros:

  • LR54 gives the same voltage as AG10, so your device works right.

  • The higher capacity (85–90 mAh) means the battery lasts longer.

  • You can find LR54 batteries in many stores.

• Cons:

  • LR54 is a bit bigger than some AG10 batteries, so it might not fit in very tight spots.

  • You need to check your device’s details to make sure LR54 fits well.

Note: Always check the fit before using LR54, especially in devices with little space.

3. 389/390

Specs

If you want a strong button cell, look at 389 and 390. These batteries use silver oxide chemistry. This gives a steady voltage and more power than most alkaline batteries. The table below shows how they are different:

The 389/390 batteries last longer than most others. Silver oxide keeps the voltage steady as the battery runs out. This helps your device work better, especially if it needs exact power.

Note: 389 is best for things that use lots of power. 390 is good for things that use less power.

Fit

You do not have to worry about the size with 389 or 390. They are the same diameter and height as the AG10 Battery. You can put them in the same spot with no problem. The fit is the same, so they will not be too loose or too tight. The main change is the chemistry, not the size. Your device will take the battery, but how it works may change based on what your gadget needs.

Pros & Cons

It is important to know the good and bad sides before you pick a 389 or 390 battery:

Pros:

• Silver oxide gives longer life and steady voltage.

• Lower self-discharge means it lasts longer when not used.

• Fits well in devices that use AG10 or LR1130.

• Works in both high-power and low-power gadgets.

Cons:

• Usually costs more than alkaline batteries.

• Might be too much for simple, low-power things.

• You cannot recharge it.

Tip: Pick 389/390 batteries for watches, medical tools, or electronics that need steady power and longer life.

4. G10A

Specs

G10A batteries are a lot like other button cells in this group. They have 1.5 volts, which is good for most small electronics. The chemistry is alkaline, made with zinc and manganese dioxide. The diameter is about 11.3 mm, so it is a little smaller than some other button cells. The thickness is 3.1 mm, so it fits well in most battery slots. The capacity is usually between 85 and 90 mAh, so it lasts longer in things that do not use much power. These batteries can last up to 3 years if you keep them in a cool, dry place. You cannot recharge them, so you use them once and then throw them away.

G10A batteries are in the same group as LR1130, LR54, and other similar types. You can use them in watches, calculators, toys, and other small electronics. The voltage and chemistry are the same as other button cells, so they work well and give steady power.

Note: G10A batteries are a little smaller than AG10, but they still work in most devices.

Fit

You can use G10A batteries in almost any device that needs an AG10, LR1130, or LR54. Product guides say G10A is a direct swap for these batteries. Here are some things to know about how they fit:

• G10A and AG10 both have 1.5 volts.

• The capacity is about the same, so battery life is similar.

• The size difference is very small, so G10A fits in most battery slots.

• You can switch G10A with LR1130, LR54, or 189 batteries with no trouble.

Most watches, calculators, and toys will take G10A batteries with no problems. You do not need to change the battery compartment or worry about loose batteries.

Pros & Cons

When you pick G10A batteries, you get some good things, but there are a few downsides too.

• This battery works in most small electronics.

• The capacity means you do not have to change it often.

• You cannot recharge these batteries.

• Sometimes, the fit is not perfect if your device needs a tight seal.

Tip: Always look at your device’s manual or battery area for the right code before you buy new batteries.

5. LR44

Specs

The LR44 battery is a popular button cell. You will find it in many small devices. It uses alkaline chemistry and gives 1.5 volts. The LR44 is a bit thicker than other button cells. Here are the main specs:

The higher capacity means the LR44 lasts longer in many devices. You can store these batteries for several years without losing much power.

Tip: Always check the battery size before you buy. The LR44 is thicker than most AG10-sized batteries.

Fit

You might want to use an LR44 as a substitute. First, check the battery compartment. The LR44 is 5.4 mm thick, while most button cells like the AG10 are only 3.1 mm thick. This extra thickness can cause problems.

• The LR44 fits only if your device has enough space.

• Some battery compartments will not close with an LR44 inside.

• If you force the battery, you could damage your device.

You should measure the old battery and the slot before you try the LR44. If the slot is too small, pick a thinner battery.

Pros & Cons

You need to know the good and bad sides of using the LR44. Here is a quick list:

Pros:

• Higher capacity gives longer use time.

• Easy to find in stores.

• Works in many toys, laser pointers, and small gadgets.

Cons:

• Too thick for most AG10 Battery slots.

• Can damage the device if forced.

• Not always a direct swap for thinner button cells.

Note: Use the LR44 only if your device manual says it is okay. Always check the fit before you buy.

AG10 Battery vs LR44

Size

There is a big size difference between these batteries. Both have a diameter of 11.6 mm, so they look alike at first. The main difference is how thick they are. The AG10 Battery is about 3.1 mm thick. The LR44 is much thicker at 5.4 mm. Because of this, the LR44 will not fit in every device that uses an AG10 Battery. If your device has a small battery space, the LR44 might not fit.

Tip: Always check how thick the battery is before you swap. Using a thicker battery can break your device.

Voltage & Capacity

Both batteries give 1.5V of power. This means they can run similar electronics. The big difference is in how much energy they hold. The AG10 Battery usually has 65-72 mAh. The LR44 can hold 110-150 mAh. The LR44 lasts longer in things that use more power.

Note: LR44 batteries last longer because they store more energy.

Performance

Both batteries work well in low-power gadgets. The LR44 is better for things that need more power or run longer. The AG10 Battery is best for devices that use less energy and have small battery spaces. If you try to use an LR44 in a spot made for AG10, it might not fit. The battery cover could stick out. Always use the right battery for your device.

Applications

The AG10 Battery is used in calculators, digital watches, key fobs, and small toys. These things need a thin battery and do not use much power. The LR44 is found in watches, calculators, thermometers, cameras, remotes, and hearing aids. Devices that need more power or have bigger battery spaces use the LR44.

Remember: Both batteries are alkaline, but you cannot always swap them. Always check your device’s manual before changing batteries.

Choosing the Right Substitute

Tips

Picking the right battery helps your device work well and last longer. Here are some easy steps to follow:

1. Make sure the voltage is 1.5 volts. This keeps your device safe.

2. Check the size and how much power it holds. The battery must fit and give enough energy.

3. Look at your device’s manual. It tells you which batteries work best.

4. Check your old battery for numbers and letters. These show the model, voltage, and power.

5. Use charts to compare batteries. They help you find ones that are the same.

6. Buy batteries from stores you trust. This way, you get real batteries that work well.

7. Watch for small changes in size or power. Even little differences, like between LR54, LR1130, or G10A, can change how your device works.

8. Think about what the battery is made of. Silver oxide batteries last longer and keep power steady, but they cost more.

9. Put the battery in the right way. Match the plus and minus sides and be gentle with the contacts.

You can use AG10-sized batteries like LR54 or 389 in many devices. If your device has a small space, pick a thinner battery. If you want it to last longer, a thicker battery like LR1130 might be better. Knowing these things helps your device work its best and last longer.

Safety

Always be careful when you use button cell batteries:

• Keep batteries away from kids and pets. They could swallow them.

• Put each battery in its own plastic bag or cover the ends with tape. This stops short circuits.

• Do not throw batteries in the trash or recycling bin. Take them to special battery recycling places.

• Be extra careful with lithium batteries. Broken batteries or touching the ends can cause sparks or fire.

• Follow all rules from the maker or your local waste center when you throw batteries away.

• Only use new batteries with the same type and voltage as the old one.

• If someone swallows a battery, get help from a doctor right away.

• Always look at the battery for safety notes and how to use it.

Safety first: Handling and throwing away batteries the right way keeps you, your family, and the earth safe.

You have several great options when replacing your battery. The most recommended substitutes include:

• LR1130

• LR54

• 189

• G10A

• LR44 (for devices with larger battery slots)

For calculators, watches, key fobs, and toys, LR1130, LR54, 189, and G10A work best because they match the size and voltage. To choose the right battery:

1. Check your device manual or old battery for the correct code.

2. Buy from trusted brands like Energizer or Maxell.

3. Make sure the voltage and size match your device.

Always follow safety tips and dispose of old batteries properly.

FAQ

What is the best AG10 battery substitute for watches?

You should use LR1130 or 389/390 batteries for watches. These batteries match the size and voltage of AG10. Silver oxide types like 389/390 last longer and give steady power.

Can you use LR44 instead of AG10 in all devices?

No, you cannot use LR44 in every device. LR44 is thicker than AG10. It only fits if your device has enough space for the extra thickness.

How do you know if a battery is compatible?

Check your device manual or the old battery code. Use a battery cross-reference chart. Make sure the new battery matches the size, voltage, and chemistry.

Are silver oxide batteries better than alkaline?

Yes, silver oxide batteries last longer and keep a steady voltage. They cost more but work better in devices that need stable power, like watches or medical tools.

What should you do with used button cell batteries?

Always recycle used batteries at a special recycling center. Do not throw them in the trash. This keeps harmful chemicals out of the environment and keeps people safe.
